Beneware-Remote ECG/BP Analysis Platform

Features	Parameters
Model	SP-01(non-LCD),SP-11(with LCD)
Interactive interface	LCD and buttons（SP-1X）
Sampling rate	UP to 200KHz
Connection type	USB or Bluetooth 5.0
USB type	USB2.0 HID free driver
Physical specifications
Size	144.8 x 50.4 x 26.3 mm
Weight	98g（SP-0X）,92g(SP-1X)
Shell	ABS+PC
Working environment
Working temperature	5 ~ +40°C
Storage temperature	-40°C ~ +55°C
Working humidity	≤95%
Storage humidity	≤95%
Working pressure	700hPa ~ 1060hPa
Storage air presssure	560hPa ~ 1060hPa
Hit	Any axial drop from 20mm height, hard surface can keep
Power supply
Supply voltage	5.0V±10%（SP-0X）或3.0V±10%（SP-1X）
Performance parameters
Vital capacity	Range 0~10L，error not more than ±3% or ±0.05L（choose bigger one）
Forced vital capacity	Range 0~10L，error not more than ±3% or ±0.05L（choose bigger one）
Peak expiratory flow	Range -16~16L/s，error not more than ±10% or ±0.3L/s（choose bigger one）
Repeatability of peak respiratory flow measurement	error not more than ±5% or ±0.15L/s（choose bigger one）
Maximum minute ventilation	Not less than 250L/min，error not more than ±10% or ±15L/min（choose bigger one）
